Sentinel1.8.6更改配置同步到nacos(项目是Gateway)

本次修改的源码在：https://gitee.com/stonic-open-source/sentinel-parent

一

下载源码 地址：https://github.com/alibaba/Sentinel/releases/tag/1.8.6

二

导入idea，等待maven下载好各种依赖

三

打开sentile-dashboard这个模块，打开resources下的application.properties配置

把下列配置加进去

#你的nacos地址
nacos.server-addr=localhost:8148
#准备把sentinel配置同步到的nacos命名空间
nacos.namespace=zixun_dev
#你的nacos用户名
nacos.username=nacos
#你的nacos密码
nacos.password=nacos

四

打开sentile-dashboard下的pom，把sentinel-datasource-nacos的<scope>test</scope>删掉(记得刷新一下maven)

五

rule文件夹下新建一个nacos目录

把图中test的NacosConfig和Util复制到nacos目录下

六

然后在nacos下新建一个NacosInfoConfig类，用于读取配置文件

import org.springframework.boot.context.properties.ConfigurationProperties;
import org.springframework.stereotype.Component;/*** @author 刘辉* @description* @since 2024/5/17 上午10:26*/
@Component
@ConfigurationProperties(prefix = "nacos")
public class NacosInfoConfig {private String serverAddr;private String username;private String password;private String namespace;public String getServerAddr() {return serverAddr;}public void setServerAddr(String serverAddr) {this.serverAddr = serverAddr;}public String getUsername() {return username;}public void setUsername(String username) {this.username = username;}public String getPassword() {return password;}public void setPassword(String password) {this.password = password;}public String getNamespace() {return namespace;}public void setNamespace(String namespace) {this.namespace = namespace;}
}

七

然后修改一下NacosConfigUtil的内容  其中group_id需要和你springcloud项目配置的nacos中sentinel的groupId一致

public final class NacosConfigUtil {/*** 同步到nacos生成的groupId 没有可不填*/public static final String GROUP_ID = "zixun_sentinel";/*** 同步到nacos生成的sentinel api规则的后缀*/public static final String API_DATA_ID_POSTFIX = "-api-rules";/*** 同步到nacos生成的sentinel 流控规则的后缀*/public static final String FLOW_DATA_ID_POSTFIX = "-flow-rules";/*** 同步到nacos生成的sentinel 参数规则的后缀*/public static final String PARAM_FLOW_DATA_ID_POSTFIX = "-param-rules";public static final String CLUSTER_MAP_DATA_ID_POSTFIX = "-cluster-map";/*** cc for `cluster-client`*/public static final String CLIENT_CONFIG_DATA_ID_POSTFIX = "-cc-config";/*** cs for `cluster-server`*/public static final String SERVER_TRANSPORT_CONFIG_DATA_ID_POSTFIX = "-cs-transport-config";public static final String SERVER_FLOW_CONFIG_DATA_ID_POSTFIX = "-cs-flow-config";public static final String SERVER_NAMESPACE_SET_DATA_ID_POSTFIX = "-cs-namespace-set";private NacosConfigUtil() {}
}

八

修改NacosConfig文件

将配置的nacos信息注入进去，且新增gateway流控配置和sentinel全局规则的配置

import java.util.List;
import java.util.Properties;import org.springframework.beans.factory.annotation.Autowired;
import org.springframework.context.annotation.Bean;
import org.springframework.context.annotation.Configuration;import com.alibaba.csp.sentinel.dashboard.datasource.entity.gateway.ApiDefinitionEntity;
import com.alibaba.csp.sentinel.dashboard.datasource.entity.gateway.GatewayFlowRuleEntity;
import com.alibaba.csp.sentinel.dashboard.datasource.entity.rule.FlowRuleEntity;
import com.alibaba.csp.sentinel.datasource.Converter;
import com.alibaba.fastjson.JSON;
import com.alibaba.nacos.api.config.ConfigFactory;
import com.alibaba.nacos.api.config.ConfigService;/*** @author Eric Zhao* @since 1.4.0*/
@Configuration
public class NacosConfig {@Autowiredprivate NacosInfoConfig nacosInfoConfig;/*** sentinel本地流控 编码器* @return*/@Beanpublic Converter<List<FlowRuleEntity>, String> flowRuleEntityEncoder() {return JSON::toJSONString;}/*** sentinel 针对gateway流控配置 编码器* @return*/@Beanpublic Converter<List<GatewayFlowRuleEntity>, String> flowRuleGatewayEntityEncoder() {return JSON::toJSONString;}/*** sentinel 针对全局流控配置 编码器* @return*/@Beanpublic Converter<List<ApiDefinitionEntity>, String> flowRuleNacosEntityEncoder() {return JSON::toJSONString;}/*** sentinel本地流控 解码器* @return*/@Beanpublic Converter<String, List<FlowRuleEntity>> flowRuleEntityDecoder() {return s -> JSON.parseArray(s, FlowRuleEntity.class);}/*** sentinel 针对gateway流控配置 解码器* @return*/@Beanpublic Converter<String, List<GatewayFlowRuleEntity>> flowRuleGatewayEntityDecoder() {return s -> JSON.parseArray(s, GatewayFlowRuleEntity.class);}/*** sentinel 针对全局流控配置 解码器* @return*/@Beanpublic Converter<String, List<ApiDefinitionEntity>> flowRuleNacosEntityDecoder() {return s -> JSON.parseArray(s, ApiDefinitionEntity.class);}@Beanpublic ConfigService nacosConfigService() throws Exception {Properties properties = new Properties();//Nacos地址properties.put("serverAddr", nacosInfoConfig.getServerAddr());//Nacos用户名properties.put("username", nacosInfoConfig.getUsername());//Nacos密码properties.put("password", nacosInfoConfig.getPassword());properties.put("namespace", nacosInfoConfig.getNamespace());return ConfigFactory.createConfigService(properties);}
}

九

新建FlowRuleGatewayProvider和FlowRuleGatewayPublisher  分别提供gateway添加和查询的操作

import java.util.ArrayList;
import java.util.List;import org.springframework.beans.factory.annotation.Autowired;
import org.springframework.beans.factory.annotation.Qualifier;
import org.springframework.stereotype.Component;import com.alibaba.csp.sentinel.dashboard.datasource.entity.gateway.GatewayFlowRuleEntity;
import com.alibaba.csp.sentinel.dashboard.rule.DynamicRuleProvider;
import com.alibaba.csp.sentinel.dashboard.rule.nacos.NacosConfigUtil;
import com.alibaba.csp.sentinel.datasource.Converter;
import com.alibaba.csp.sentinel.util.StringUtil;
import com.alibaba.nacos.api.config.ConfigService;/*** @author Eric Zhao* @since 1.4.0*/
@Component("flowRuleGatewayProvider")
public class FlowRuleGatewayProvider implements DynamicRuleProvider<List<GatewayFlowRuleEntity>> {@Autowiredprivate ConfigService configService;@Autowired@Qualifier("flowRuleGatewayEntityDecoder")private Converter<String, List<GatewayFlowRuleEntity>> converter;@Overridepublic List<GatewayFlowRuleEntity> getRules(String appName) throws Exception {String rules = configService.getConfig(appName + NacosConfigUtil.FLOW_DATA_ID_POSTFIX,NacosConfigUtil.GROUP_ID, 3000);if (StringUtil.isEmpty(rules)) {return new ArrayList<>();}return converter.convert(rules);}
}

import java.util.List;import org.springframework.beans.factory.annotation.Autowired;
import org.springframework.beans.factory.annotation.Qualifier;
import org.springframework.stereotype.Component;import com.alibaba.csp.sentinel.dashboard.datasource.entity.gateway.GatewayFlowRuleEntity;
import com.alibaba.csp.sentinel.dashboard.rule.DynamicRulePublisher;
import com.alibaba.csp.sentinel.dashboard.rule.nacos.NacosConfigUtil;
import com.alibaba.csp.sentinel.datasource.Converter;
import com.alibaba.csp.sentinel.util.AssertUtil;
import com.alibaba.nacos.api.config.ConfigService;
import com.alibaba.nacos.api.config.ConfigType;/*** @author Eric Zhao* @since 1.4.0*/
@Component("flowRuleGatewayPublisher")
public class FlowRuleGatewayPublisher implements DynamicRulePublisher<List<GatewayFlowRuleEntity>> {@Autowiredprivate ConfigService configService;@Autowired@Qualifier("flowRuleGatewayEntityEncoder")private Converter<List<GatewayFlowRuleEntity>, String> converter;@Overridepublic void publish(String app, List<GatewayFlowRuleEntity> rules) throws Exception {AssertUtil.notEmpty(app, "app name cannot be empty");if (rules == null) {return;}configService.publishConfig(app + NacosConfigUtil.FLOW_DATA_ID_POSTFIX,NacosConfigUtil.GROUP_ID, converter.convert(rules), ConfigType.JSON.getType());}
}

新建FlowRuleApiProvider和FlowRuleApiPublisher  分别提供sentinel全局规则 查询和编辑

import java.util.ArrayList;
import java.util.List;import org.springframework.beans.factory.annotation.Autowired;
import org.springframework.beans.factory.annotation.Qualifier;
import org.springframework.stereotype.Component;import com.alibaba.csp.sentinel.dashboard.datasource.entity.gateway.ApiDefinitionEntity;
import com.alibaba.csp.sentinel.dashboard.rule.DynamicRuleProvider;
import com.alibaba.csp.sentinel.dashboard.rule.nacos.NacosConfigUtil;
import com.alibaba.csp.sentinel.datasource.Converter;
import com.alibaba.csp.sentinel.util.StringUtil;
import com.alibaba.nacos.api.config.ConfigService;/*** @author Eric Zhao* @since 1.4.0*/
@Component("flowRuleNacosProvider")
public class FlowRuleApiProvider implements DynamicRuleProvider<List<ApiDefinitionEntity>> {@Autowiredprivate ConfigService configService;@Autowired@Qualifier("flowRuleNacosEntityDecoder")private Converter<String, List<ApiDefinitionEntity>> converter;@Overridepublic List<ApiDefinitionEntity> getRules(String appName) throws Exception {String rules = configService.getConfig(appName + NacosConfigUtil.API_DATA_ID_POSTFIX,NacosConfigUtil.GROUP_ID, 3000);if (StringUtil.isEmpty(rules)) {return new ArrayList<>();}return converter.convert(rules);}
}

import java.util.List;import org.springframework.beans.factory.annotation.Autowired;
import org.springframework.beans.factory.annotation.Qualifier;
import org.springframework.stereotype.Component;import com.alibaba.csp.sentinel.dashboard.datasource.entity.gateway.ApiDefinitionEntity;
import com.alibaba.csp.sentinel.dashboard.rule.DynamicRulePublisher;
import com.alibaba.csp.sentinel.dashboard.rule.nacos.NacosConfigUtil;
import com.alibaba.csp.sentinel.datasource.Converter;
import com.alibaba.csp.sentinel.util.AssertUtil;
import com.alibaba.nacos.api.config.ConfigService;
import com.alibaba.nacos.api.config.ConfigType;/*** @author Eric Zhao* @since 1.4.0*/
@Component("flowRuleNacosPublisher")
public class FlowRuleApiPublisher implements DynamicRulePublisher<List<ApiDefinitionEntity>> {@Autowiredprivate ConfigService configService;@Autowired@Qualifier("flowRuleNacosEntityEncoder")private Converter<List<ApiDefinitionEntity>, String> converter;@Overridepublic void publish(String app, List<ApiDefinitionEntity> rules) throws Exception {AssertUtil.notEmpty(app, "app name cannot be empty");if (rules == null) {return;}configService.publishConfig(app + NacosConfigUtil.API_DATA_ID_POSTFIX,NacosConfigUtil.GROUP_ID, converter.convert(rules), ConfigType.JSON.getType());}
}

自此配置方面就结束了，接下来上controller代码

十

找到controller下的gateway目录两个controller

下边的增删改查方法都有修改，修改的地方比较多，这里我直接贴主要替换的代码和controller全部代码大家直接粘贴

GatewayApiController修改处：


    @Autowired@Qualifier("flowRuleNacosProvider")private DynamicRuleProvider<List<ApiDefinitionEntity>> ruleProvider;@Autowired@Qualifier("flowRuleNacosPublisher")private DynamicRulePublisher<List<ApiDefinitionEntity>> rulePublisher;

package com.alibaba.csp.sentinel.dashboard.controller.gateway;import com.alibaba.csp.sentinel.dashboard.auth.AuthAction;
import com.alibaba.csp.sentinel.dashboard.auth.AuthService;
import com.alibaba.csp.sentinel.dashboard.client.SentinelApiClient;
import com.alibaba.csp.sentinel.dashboard.datasource.entity.gateway.ApiDefinitionEntity;
import com.alibaba.csp.sentinel.dashboard.datasource.entity.gateway.ApiPredicateItemEntity;
import com.alibaba.csp.sentinel.dashboard.discovery.MachineInfo;
import com.alibaba.csp.sentinel.dashboard.domain.Result;
import com.alibaba.csp.sentinel.dashboard.domain.vo.gateway.api.AddApiReqVo;
import com.alibaba.csp.sentinel.dashboard.domain.vo.gateway.api.ApiPredicateItemVo;
import com.alibaba.csp.sentinel.dashboard.domain.vo.gateway.api.UpdateApiReqVo;
import com.alibaba.csp.sentinel.dashboard.repository.gateway.InMemApiDefinitionStore;
import com.alibaba.csp.sentinel.dashboard.rule.DynamicRuleProvider;
import com.alibaba.csp.sentinel.dashboard.rule.DynamicRulePublisher;
import com.alibaba.csp.sentinel.util.StringUtil;
import org.slf4j.Logger;
import org.slf4j.LoggerFactory;
import org.springframework.beans.factory.annotation.Autowired;
import org.springframework.beans.factory.annotation.Qualifier;
import org.springframework.util.CollectionUtils;
import org.springframework.web.bind.annotation.*;import javax.servlet.http.HttpServletRequest;
import java.util.*;import static com.alibaba.csp.sentinel.adapter.gateway.common.SentinelGatewayConstants.*;/*** Gateway api Controller for manage gateway api definitions.** @author cdfive* @since 1.7.0*/
@RestController
@RequestMapping(value = "/gateway/api")
public class GatewayApiController {private final Logger logger = LoggerFactory.getLogger(GatewayApiController.class);@Autowiredprivate InMemApiDefinitionStore repository;@Autowiredprivate SentinelApiClient sentinelApiClient;@Autowired@Qualifier("flowRuleNacosProvider")private DynamicRuleProvider<List<ApiDefinitionEntity>> ruleProvider;@Autowired@Qualifier("flowRuleNacosPublisher")private DynamicRulePublisher<List<ApiDefinitionEntity>> rulePublisher;@GetMapping("/list.json")@AuthAction(AuthService.PrivilegeType.READ_RULE)public Result<List<ApiDefinitionEntity>> queryApis(String app, String ip, Integer port) {if (StringUtil.isEmpty(app)) {return Result.ofFail(-1, "app can't be null or empty");}if (StringUtil.isEmpty(ip)) {return Result.ofFail(-1, "ip can't be null or empty");}if (port == null) {return Result.ofFail(-1, "port can't be null");}try {List<ApiDefinitionEntity> apis = ruleProvider.getRules(app);
//            List<ApiDefinitionEntity> apis = sentinelApiClient.fetchApis(app, ip, port).get();repository.saveAll(apis);return Result.ofSuccess(apis);} catch (Throwable throwable) {logger.error("queryApis error:", throwable);return Result.ofThrowable(-1, throwable);}}@PostMapping("/new.json")@AuthAction(AuthService.PrivilegeType.WRITE_RULE)public Result<ApiDefinitionEntity> addApi(HttpServletRequest request, @RequestBody AddApiReqVo reqVo) {String app = reqVo.getApp();if (StringUtil.isBlank(app)) {return Result.ofFail(-1, "app can't be null or empty");}ApiDefinitionEntity entity = new ApiDefinitionEntity();entity.setApp(app.trim());String ip = reqVo.getIp();if (StringUtil.isBlank(ip)) {return Result.ofFail(-1, "ip can't be null or empty");}entity.setIp(ip.trim());Integer port = reqVo.getPort();if (port == null) {return Result.ofFail(-1, "port can't be null");}entity.setPort(port);// API名称String apiName = reqVo.getApiName();if (StringUtil.isBlank(apiName)) {return Result.ofFail(-1, "apiName can't be null or empty");}entity.setApiName(apiName.trim());// 匹配规则列表List<ApiPredicateItemVo> predicateItems = reqVo.getPredicateItems();if (CollectionUtils.isEmpty(predicateItems)) {return Result.ofFail(-1, "predicateItems can't empty");}List<ApiPredicateItemEntity> predicateItemEntities = new ArrayList<>();for (ApiPredicateItemVo predicateItem : predicateItems) {ApiPredicateItemEntity predicateItemEntity = new ApiPredicateItemEntity();// 匹配模式Integer matchStrategy = predicateItem.getMatchStrategy();if (!Arrays.asList(URL_MATCH_STRATEGY_EXACT, URL_MATCH_STRATEGY_PREFIX, URL_MATCH_STRATEGY_REGEX).contains(matchStrategy)) {return Result.ofFail(-1, "invalid matchStrategy: " + matchStrategy);}predicateItemEntity.setMatchStrategy(matchStrategy);// 匹配串String pattern = predicateItem.getPattern();if (StringUtil.isBlank(pattern)) {return Result.ofFail(-1, "pattern can't be null or empty");}predicateItemEntity.setPattern(pattern);predicateItemEntities.add(predicateItemEntity);}entity.setPredicateItems(new LinkedHashSet<>(predicateItemEntities));// 检查API名称不能重复List<ApiDefinitionEntity> allApis = repository.findAllByMachine(MachineInfo.of(app.trim(), ip.trim(), port));if (allApis.stream().map(o -> o.getApiName()).anyMatch(o -> o.equals(apiName.trim()))) {return Result.ofFail(-1, "apiName exists: " + apiName);}Date date = new Date();entity.setGmtCreate(date);entity.setGmtModified(date);try {entity = repository.save(entity);publishApis(entity.getApp());} catch (Throwable throwable) {logger.error("add gateway api error:", throwable);return Result.ofThrowable(-1, throwable);}//        if (!publishApis(app, ip, port)) {
//            logger.warn("publish gateway apis fail after add");
//        }return Result.ofSuccess(entity);}@PostMapping("/save.json")@AuthAction(AuthService.PrivilegeType.WRITE_RULE)public Result<ApiDefinitionEntity> updateApi(@RequestBody UpdateApiReqVo reqVo) {String app = reqVo.getApp();if (StringUtil.isBlank(app)) {return Result.ofFail(-1, "app can't be null or empty");}Long id = reqVo.getId();if (id == null) {return Result.ofFail(-1, "id can't be null");}ApiDefinitionEntity entity = repository.findById(id);if (entity == null) {return Result.ofFail(-1, "api does not exist, id=" + id);}// 匹配规则列表List<ApiPredicateItemVo> predicateItems = reqVo.getPredicateItems();if (CollectionUtils.isEmpty(predicateItems)) {return Result.ofFail(-1, "predicateItems can't empty");}List<ApiPredicateItemEntity> predicateItemEntities = new ArrayList<>();for (ApiPredicateItemVo predicateItem : predicateItems) {ApiPredicateItemEntity predicateItemEntity = new ApiPredicateItemEntity();// 匹配模式int matchStrategy = predicateItem.getMatchStrategy();if (!Arrays.asList(URL_MATCH_STRATEGY_EXACT, URL_MATCH_STRATEGY_PREFIX, URL_MATCH_STRATEGY_REGEX).contains(matchStrategy)) {return Result.ofFail(-1, "Invalid matchStrategy: " + matchStrategy);}predicateItemEntity.setMatchStrategy(matchStrategy);// 匹配串String pattern = predicateItem.getPattern();if (StringUtil.isBlank(pattern)) {return Result.ofFail(-1, "pattern can't be null or empty");}predicateItemEntity.setPattern(pattern);predicateItemEntities.add(predicateItemEntity);}entity.setPredicateItems(new LinkedHashSet<>(predicateItemEntities));Date date = new Date();entity.setGmtModified(date);try {entity = repository.save(entity);publishApis(entity.getApp());} catch (Throwable throwable) {logger.error("update gateway api error:", throwable);return Result.ofThrowable(-1, throwable);}//        if (!publishApis(app, entity.getIp(), entity.getPort())) {
//            logger.warn("publish gateway apis fail after update");
//        }return Result.ofSuccess(entity);}@PostMapping("/delete.json")@AuthAction(AuthService.PrivilegeType.DELETE_RULE)public Result<Long> deleteApi(Long id) {if (id == null) {return Result.ofFail(-1, "id can't be null");}ApiDefinitionEntity oldEntity = repository.findById(id);if (oldEntity == null) {return Result.ofSuccess(null);}try {repository.delete(id);publishApis(oldEntity.getApp());} catch (Throwable throwable) {logger.error("delete gateway api error:", throwable);return Result.ofThrowable(-1, throwable);}//        if (!publishApis(oldEntity.getApp(), oldEntity.getIp(), oldEntity.getPort())) {
//            logger.warn("publish gateway apis fail after delete");
//        }return Result.ofSuccess(id);}//    private boolean publishApis(String app, String ip, Integer port) {
//        List<ApiDefinitionEntity> apis = repository.findAllByMachine(MachineInfo.of(app, ip, port));
//        return sentinelApiClient.modifyApis(app, ip, port, apis);
//    }private void publishApis(/*@NonNull*/ String app) throws Exception {List<ApiDefinitionEntity> rules = repository.findAllByApp(app);rulePublisher.publish(app, rules);}
}

GatewayFlowRuleController修改为：

    @Autowired@Qualifier("flowRuleGatewayProvider")private DynamicRuleProvider<List<GatewayFlowRuleEntity>> ruleProvider;@Autowired@Qualifier("flowRuleGatewayPublisher")private DynamicRulePublisher<List<GatewayFlowRuleEntity>> rulePublisher;

package com.alibaba.csp.sentinel.dashboard.controller.gateway;import com.alibaba.csp.sentinel.dashboard.auth.AuthAction;
import com.alibaba.csp.sentinel.dashboard.auth.AuthService;
import com.alibaba.csp.sentinel.dashboard.client.SentinelApiClient;
import com.alibaba.csp.sentinel.dashboard.datasource.entity.gateway.GatewayFlowRuleEntity;
import com.alibaba.csp.sentinel.dashboard.datasource.entity.gateway.GatewayParamFlowItemEntity;
import com.alibaba.csp.sentinel.dashboard.datasource.entity.rule.FlowRuleEntity;
import com.alibaba.csp.sentinel.dashboard.discovery.MachineInfo;
import com.alibaba.csp.sentinel.dashboard.domain.Result;
import com.alibaba.csp.sentinel.dashboard.domain.vo.gateway.rule.AddFlowRuleReqVo;
import com.alibaba.csp.sentinel.dashboard.domain.vo.gateway.rule.GatewayParamFlowItemVo;
import com.alibaba.csp.sentinel.dashboard.domain.vo.gateway.rule.UpdateFlowRuleReqVo;
import com.alibaba.csp.sentinel.dashboard.repository.gateway.InMemGatewayFlowRuleStore;
import com.alibaba.csp.sentinel.dashboard.rule.DynamicRuleProvider;
import com.alibaba.csp.sentinel.dashboard.rule.DynamicRulePublisher;
import com.alibaba.csp.sentinel.util.StringUtil;
import org.slf4j.Logger;
import org.slf4j.LoggerFactory;
import org.springframework.beans.factory.annotation.Autowired;
import org.springframework.beans.factory.annotation.Qualifier;
import org.springframework.web.bind.annotation.*;import java.util.Arrays;
import java.util.Date;
import java.util.List;import static com.alibaba.csp.sentinel.slots.block.RuleConstant.*;
import static com.alibaba.csp.sentinel.adapter.gateway.common.SentinelGatewayConstants.*;
import static com.alibaba.csp.sentinel.dashboard.datasource.entity.gateway.GatewayFlowRuleEntity.*;/*** Gateway flow rule Controller for manage gateway flow rules.** @author cdfive* @since 1.7.0*/
@RestController
@RequestMapping(value = "/gateway/flow")
public class GatewayFlowRuleController {private final Logger logger = LoggerFactory.getLogger(GatewayFlowRuleController.class);@Autowiredprivate InMemGatewayFlowRuleStore repository;@Autowiredprivate SentinelApiClient sentinelApiClient;@Autowired@Qualifier("flowRuleGatewayProvider")private DynamicRuleProvider<List<GatewayFlowRuleEntity>> ruleProvider;@Autowired@Qualifier("flowRuleGatewayPublisher")private DynamicRulePublisher<List<GatewayFlowRuleEntity>> rulePublisher;@GetMapping("/list.json")@AuthAction(AuthService.PrivilegeType.READ_RULE)public Result<List<GatewayFlowRuleEntity>> queryFlowRules(String app, String ip, Integer port) {if (StringUtil.isEmpty(app)) {return Result.ofFail(-1, "app can't be null or empty");}if (StringUtil.isEmpty(ip)) {return Result.ofFail(-1, "ip can't be null or empty");}if (port == null) {return Result.ofFail(-1, "port can't be null");}//        try {
//            List<GatewayFlowRuleEntity> rules = sentinelApiClient.fetchGatewayFlowRules(app, ip, port).get();
//            repository.saveAll(rules);
//            return Result.ofSuccess(rules);
//        } catch (Throwable throwable) {
//            logger.error("query gateway flow rules error:", throwable);
//            return Result.ofThrowable(-1, throwable);
//        }try {List<GatewayFlowRuleEntity> rules = ruleProvider.getRules(app);rules = repository.saveAll(rules);return Result.ofSuccess(rules);} catch (Throwable throwable) {logger.error("Error when querying flow rules", throwable);return Result.ofThrowable(-1, throwable);}}@PostMapping("/new.json")@AuthAction(AuthService.PrivilegeType.WRITE_RULE)public Result<GatewayFlowRuleEntity> addFlowRule(@RequestBody AddFlowRuleReqVo reqVo) {String app = reqVo.getApp();if (StringUtil.isBlank(app)) {return Result.ofFail(-1, "app can't be null or empty");}GatewayFlowRuleEntity entity = new GatewayFlowRuleEntity();entity.setApp(app.trim());String ip = reqVo.getIp();if (StringUtil.isBlank(ip)) {return Result.ofFail(-1, "ip can't be null or empty");}entity.setIp(ip.trim());Integer port = reqVo.getPort();if (port == null) {return Result.ofFail(-1, "port can't be null");}entity.setPort(port);// API类型, Route ID或API分组Integer resourceMode = reqVo.getResourceMode();if (resourceMode == null) {return Result.ofFail(-1, "resourceMode can't be null");}if (!Arrays.asList(RESOURCE_MODE_ROUTE_ID, RESOURCE_MODE_CUSTOM_API_NAME).contains(resourceMode)) {return Result.ofFail(-1, "invalid resourceMode: " + resourceMode);}entity.setResourceMode(resourceMode);// API名称String resource = reqVo.getResource();if (StringUtil.isBlank(resource)) {return Result.ofFail(-1, "resource can't be null or empty");}entity.setResource(resource.trim());// 针对请求属性GatewayParamFlowItemVo paramItem = reqVo.getParamItem();if (paramItem != null) {GatewayParamFlowItemEntity itemEntity = new GatewayParamFlowItemEntity();entity.setParamItem(itemEntity);// 参数属性 0-ClientIP 1-Remote Host 2-Header 3-URL参数 4-CookieInteger parseStrategy = paramItem.getParseStrategy();if (!Arrays.asList(PARAM_PARSE_STRATEGY_CLIENT_IP, PARAM_PARSE_STRATEGY_HOST, PARAM_PARSE_STRATEGY_HEADER, PARAM_PARSE_STRATEGY_URL_PARAM, PARAM_PARSE_STRATEGY_COOKIE).contains(parseStrategy)) {return Result.ofFail(-1, "invalid parseStrategy: " + parseStrategy);}itemEntity.setParseStrategy(paramItem.getParseStrategy());// 当参数属性为2-Header 3-URL参数 4-Cookie时，参数名称必填if (Arrays.asList(PARAM_PARSE_STRATEGY_HEADER, PARAM_PARSE_STRATEGY_URL_PARAM, PARAM_PARSE_STRATEGY_COOKIE).contains(parseStrategy)) {// 参数名称String fieldName = paramItem.getFieldName();if (StringUtil.isBlank(fieldName)) {return Result.ofFail(-1, "fieldName can't be null or empty");}itemEntity.setFieldName(paramItem.getFieldName());}String pattern = paramItem.getPattern();// 如果匹配串不为空，验证匹配模式if (StringUtil.isNotEmpty(pattern)) {itemEntity.setPattern(pattern);Integer matchStrategy = paramItem.getMatchStrategy();if (!Arrays.asList(PARAM_MATCH_STRATEGY_EXACT, PARAM_MATCH_STRATEGY_CONTAINS, PARAM_MATCH_STRATEGY_REGEX).contains(matchStrategy)) {return Result.ofFail(-1, "invalid matchStrategy: " + matchStrategy);}itemEntity.setMatchStrategy(matchStrategy);}}// 阈值类型 0-线程数 1-QPSInteger grade = reqVo.getGrade();if (grade == null) {return Result.ofFail(-1, "grade can't be null");}if (!Arrays.asList(FLOW_GRADE_THREAD, FLOW_GRADE_QPS).contains(grade)) {return Result.ofFail(-1, "invalid grade: " + grade);}entity.setGrade(grade);// QPS阈值Double count = reqVo.getCount();if (count == null) {return Result.ofFail(-1, "count can't be null");}if (count < 0) {return Result.ofFail(-1, "count should be at lease zero");}entity.setCount(count);// 间隔Long interval = reqVo.getInterval();if (interval == null) {return Result.ofFail(-1, "interval can't be null");}if (interval <= 0) {return Result.ofFail(-1, "interval should be greater than zero");}entity.setInterval(interval);// 间隔单位Integer intervalUnit = reqVo.getIntervalUnit();if (intervalUnit == null) {return Result.ofFail(-1, "intervalUnit can't be null");}if (!Arrays.asList(INTERVAL_UNIT_SECOND, INTERVAL_UNIT_MINUTE, INTERVAL_UNIT_HOUR, INTERVAL_UNIT_DAY).contains(intervalUnit)) {return Result.ofFail(-1, "Invalid intervalUnit: " + intervalUnit);}entity.setIntervalUnit(intervalUnit);// 流控方式 0-快速失败 2-匀速排队Integer controlBehavior = reqVo.getControlBehavior();if (controlBehavior == null) {return Result.ofFail(-1, "controlBehavior can't be null");}if (!Arrays.asList(CONTROL_BEHAVIOR_DEFAULT, CONTROL_BEHAVIOR_RATE_LIMITER).contains(controlBehavior)) {return Result.ofFail(-1, "invalid controlBehavior: " + controlBehavior);}entity.setControlBehavior(controlBehavior);if (CONTROL_BEHAVIOR_DEFAULT == controlBehavior) {// 0-快速失败, 则Burst size必填Integer burst = reqVo.getBurst();if (burst == null) {return Result.ofFail(-1, "burst can't be null");}if (burst < 0) {return Result.ofFail(-1, "invalid burst: " + burst);}entity.setBurst(burst);} else if (CONTROL_BEHAVIOR_RATE_LIMITER == controlBehavior) {// 1-匀速排队, 则超时时间必填Integer maxQueueingTimeoutMs = reqVo.getMaxQueueingTimeoutMs();if (maxQueueingTimeoutMs == null) {return Result.ofFail(-1, "maxQueueingTimeoutMs can't be null");}if (maxQueueingTimeoutMs < 0) {return Result.ofFail(-1, "invalid maxQueueingTimeoutMs: " + maxQueueingTimeoutMs);}entity.setMaxQueueingTimeoutMs(maxQueueingTimeoutMs);}Date date = new Date();entity.setGmtCreate(date);entity.setGmtModified(date);try {entity = repository.save(entity);publishRules(entity.getApp());} catch (Throwable throwable) {logger.error("add gateway flow rule error:", throwable);return Result.ofThrowable(-1, throwable);}//        if (!publishRules(app, ip, port)) {
//            logger.warn("publish gateway flow rules fail after add");
//        }return Result.ofSuccess(entity);}@PostMapping("/save.json")@AuthAction(AuthService.PrivilegeType.WRITE_RULE)public Result<GatewayFlowRuleEntity> updateFlowRule(@RequestBody UpdateFlowRuleReqVo reqVo) {String app = reqVo.getApp();if (StringUtil.isBlank(app)) {return Result.ofFail(-1, "app can't be null or empty");}Long id = reqVo.getId();if (id == null) {return Result.ofFail(-1, "id can't be null");}GatewayFlowRuleEntity entity = repository.findById(id);if (entity == null) {return Result.ofFail(-1, "gateway flow rule does not exist, id=" + id);}// 针对请求属性GatewayParamFlowItemVo paramItem = reqVo.getParamItem();if (paramItem != null) {GatewayParamFlowItemEntity itemEntity = new GatewayParamFlowItemEntity();entity.setParamItem(itemEntity);// 参数属性 0-ClientIP 1-Remote Host 2-Header 3-URL参数 4-CookieInteger parseStrategy = paramItem.getParseStrategy();if (!Arrays.asList(PARAM_PARSE_STRATEGY_CLIENT_IP, PARAM_PARSE_STRATEGY_HOST, PARAM_PARSE_STRATEGY_HEADER, PARAM_PARSE_STRATEGY_URL_PARAM, PARAM_PARSE_STRATEGY_COOKIE).contains(parseStrategy)) {return Result.ofFail(-1, "invalid parseStrategy: " + parseStrategy);}itemEntity.setParseStrategy(paramItem.getParseStrategy());// 当参数属性为2-Header 3-URL参数 4-Cookie时，参数名称必填if (Arrays.asList(PARAM_PARSE_STRATEGY_HEADER, PARAM_PARSE_STRATEGY_URL_PARAM, PARAM_PARSE_STRATEGY_COOKIE).contains(parseStrategy)) {// 参数名称String fieldName = paramItem.getFieldName();if (StringUtil.isBlank(fieldName)) {return Result.ofFail(-1, "fieldName can't be null or empty");}itemEntity.setFieldName(paramItem.getFieldName());}String pattern = paramItem.getPattern();// 如果匹配串不为空，验证匹配模式if (StringUtil.isNotEmpty(pattern)) {itemEntity.setPattern(pattern);Integer matchStrategy = paramItem.getMatchStrategy();if (!Arrays.asList(PARAM_MATCH_STRATEGY_EXACT, PARAM_MATCH_STRATEGY_CONTAINS, PARAM_MATCH_STRATEGY_REGEX).contains(matchStrategy)) {return Result.ofFail(-1, "invalid matchStrategy: " + matchStrategy);}itemEntity.setMatchStrategy(matchStrategy);}} else {entity.setParamItem(null);}// 阈值类型 0-线程数 1-QPSInteger grade = reqVo.getGrade();if (grade == null) {return Result.ofFail(-1, "grade can't be null");}if (!Arrays.asList(FLOW_GRADE_THREAD, FLOW_GRADE_QPS).contains(grade)) {return Result.ofFail(-1, "invalid grade: " + grade);}entity.setGrade(grade);// QPS阈值Double count = reqVo.getCount();if (count == null) {return Result.ofFail(-1, "count can't be null");}if (count < 0) {return Result.ofFail(-1, "count should be at lease zero");}entity.setCount(count);// 间隔Long interval = reqVo.getInterval();if (interval == null) {return Result.ofFail(-1, "interval can't be null");}if (interval <= 0) {return Result.ofFail(-1, "interval should be greater than zero");}entity.setInterval(interval);// 间隔单位Integer intervalUnit = reqVo.getIntervalUnit();if (intervalUnit == null) {return Result.ofFail(-1, "intervalUnit can't be null");}if (!Arrays.asList(INTERVAL_UNIT_SECOND, INTERVAL_UNIT_MINUTE, INTERVAL_UNIT_HOUR, INTERVAL_UNIT_DAY).contains(intervalUnit)) {return Result.ofFail(-1, "Invalid intervalUnit: " + intervalUnit);}entity.setIntervalUnit(intervalUnit);// 流控方式 0-快速失败 2-匀速排队Integer controlBehavior = reqVo.getControlBehavior();if (controlBehavior == null) {return Result.ofFail(-1, "controlBehavior can't be null");}if (!Arrays.asList(CONTROL_BEHAVIOR_DEFAULT, CONTROL_BEHAVIOR_RATE_LIMITER).contains(controlBehavior)) {return Result.ofFail(-1, "invalid controlBehavior: " + controlBehavior);}entity.setControlBehavior(controlBehavior);if (CONTROL_BEHAVIOR_DEFAULT == controlBehavior) {// 0-快速失败, 则Burst size必填Integer burst = reqVo.getBurst();if (burst == null) {return Result.ofFail(-1, "burst can't be null");}if (burst < 0) {return Result.ofFail(-1, "invalid burst: " + burst);}entity.setBurst(burst);} else if (CONTROL_BEHAVIOR_RATE_LIMITER == controlBehavior) {// 2-匀速排队, 则超时时间必填Integer maxQueueingTimeoutMs = reqVo.getMaxQueueingTimeoutMs();if (maxQueueingTimeoutMs == null) {return Result.ofFail(-1, "maxQueueingTimeoutMs can't be null");}if (maxQueueingTimeoutMs < 0) {return Result.ofFail(-1, "invalid maxQueueingTimeoutMs: " + maxQueueingTimeoutMs);}entity.setMaxQueueingTimeoutMs(maxQueueingTimeoutMs);}Date date = new Date();entity.setGmtModified(date);try {entity = repository.save(entity);publishRules(entity.getApp());} catch (Throwable throwable) {logger.error("update gateway flow rule error:", throwable);return Result.ofThrowable(-1, throwable);}//        if (!publishRules(app, entity.getIp(), entity.getPort())) {
//            logger.warn("publish gateway flow rules fail after update");
//        }return Result.ofSuccess(entity);}@PostMapping("/delete.json")@AuthAction(AuthService.PrivilegeType.DELETE_RULE)public Result<Long> deleteFlowRule(Long id) {if (id == null) {return Result.ofFail(-1, "id can't be null");}GatewayFlowRuleEntity oldEntity = repository.findById(id);if (oldEntity == null) {return Result.ofSuccess(null);}try {repository.delete(id);publishRules(oldEntity.getApp());} catch (Throwable throwable) {logger.error("delete gateway flow rule error:", throwable);return Result.ofThrowable(-1, throwable);}//        if (!publishRules(oldEntity.getApp(), oldEntity.getIp(), oldEntity.getPort())) {
//            logger.warn("publish gateway flow rules fail after delete");
//        }return Result.ofSuccess(id);}//    private boolean publishRules(String app, String ip, Integer port) {
//        List<GatewayFlowRuleEntity> rules = repository.findAllByMachine(MachineInfo.of(app, ip, port));
//        return sentinelApiClient.modifyGatewayFlowRules(app, ip, port, rules);
//    }
private void publishRules(/*@NonNull*/ String app) throws Exception {List<GatewayFlowRuleEntity> rules = repository.findAllByApp(app);rulePublisher.publish(app, rules);
}
}

十一

启动程序

然后添加流控规则，查询规则都从nacos获取

至此就没问题了
